Balcony power station 800W complete solution for tiled roofs

Balcony power station 800W complete solution for tiled roofs

The set consists of:

Make a selection:

(1) 2x solar module Trina Solar 440 Wp (bifacial) or

(2) 2x solar module Trina Solar 440 Wp (FullBlack) or

(3) 2x solar module Trina Solar 455 Wp (zebra optics)

Always included in the set:

1x microinverter Hoymiles HMS-800-2T WiFi version

1x AC connection cable (230V) a 5m

4x DC extension cables (3m each)

Complete mounting material (2 solar modules) for a tile or plain tile roof

With this system you can save up to €320 per year!*

The solar module:

(Variant 1) Trina Solar 440W Double Glass (FullBlack)

Type: TSM-440-NEG9R.25

Weight in kg: approx. 21.0

Dimensions (H x W x D) in mm: 1762 x 1134 x 30

Efficiency: 22.3%

Frame: black

Product warranty: 25 years

Linear performance guarantee: 30 years

Maximum power per module: 440 watts

Max. system voltage: 1500 V

(Variant 2) Trina Solar 440W double glass (bifacial)

Type: TSM-440-NEG9RC.27

Weight in kg: approx. 21.0

Dimensions (H x W x D) in mm: 1762 x 1134 x 30

Efficiency: 22.0%

Frame: black

Product warranty: 25 years

Linear performance guarantee: 30 years

Maximum power per module: 440 watts

Max. system voltage: 1500 V

(Variant 3) Trina Solar 455W double glass (zebra optics)

Type: TSM-455-NEG9R.28

Weight in kg: approx. 21.0

Dimensions (H x W x D) in mm: 1762 x 1134 x 30

Efficiency: 22.5%

Frame: black

Product warranty: 25 years

Linear performance guarantee: 30 years

Maximum power per module: 455 watts

Max. system voltage: 1500 V

The inverter:

Hoymiles micro inverter HMS-800-2T WiFi version (800W)

• Recommended module power: up to 540 W (per module)
• Peak power MPPT voltage range: 16~60 V
• Starting voltage: 22 V
• Battery voltage range: 16~60 V
• maximum input voltage: 65 V
• maximum input current: 2x 14 A
• Maximum input short-circuit current: 2x 25 A
• Rated output power: 800 VA
• Rated output current: 3.48 A at 230 V
• Nominal output voltage/range: 230 V / 180-275 V
• CEC-weighted efficiency: 96.70%
• Ambient temperature range: -40~+65 °C
• Dimensions (W x H x D): 261 x 180 x 35.1 mm
• Weight: 3.2 kg
• Housing rating: IP67

The mounting material from Schletter:

You will receive safe, approved, and tested mounting materials from Schletter.

We assemble the material individually to match the planned module arrangement.

• Mounting rail system Schletter in suitable length
• Connector / rail connector for mounting rail
• Drilling screws M6x25 (for fixing the connector in the mounting rail)
• Module holder (center clamp, black)
• Module holder (end clamp, black)
• Roof hooks*² (quantity depends on the rafter spacing)
• Wood screws with flat head (M6x100mm)
• End caps for profile rails

Notes:

The set can be connected to your home's electrical system via a grounded outlet. Any electrical work on the home's electrical system may require the involvement of a qualified electrician.

Registration with the network operator: The customer must inform himself about all conditions regarding assembly, installation and operation as well as registration with local network operators, tax authorities and the Federal Network Agency in the market data register before purchasing.

We expressly point out that by confirming our General Terms and Conditions you also confirm that you as an end customer meet the requirements of Section 12 Paragraph 3 of the German VAT Act (UStG) and can therefore purchase the offered product with a VAT rate of 0.0% (General Terms and Conditions Section 4.4).

* The annual savings were calculated based on a generated output of 800 kWh per year and a working price of 40 cents per kWh with optimal module alignment. The savings increase with rising electricity prices. Plug & Play - The 800 W balcony power station from SolarLager24® can be connected in just a few minutes. It is versatile , suitable for installation on a balcony, a roof, a garage, a patio, or even freestanding in the garden. You can connect it yourself.
